1940 Stearman restoration (moved from Triumph forum so all can enjoy)

[CJD]

The one long strip that I must re-use is the upper one, which provides a means of attaching the arches to the frame. My upper strip was mangled, so I had to use heat and time tapping it into a straight piece once again. I did this using a 2x2" beam of structural aluminum:

Once I had a straight upper strip, I started clamping it to the frame...easier said than done. It seems that, since the frame is straight, and the cages are curved, every single clamp is unique....uhggg! I had about half of the required clamps. The other 20 or so had to be fashioned off blueprints to spec.

But, here is the installed upper strip, with the left side arches rivetted to it.

There are, of course, more unique clamps holding the bottom of EACH arch to the bottom of the frame. I am still in the process of tweaking each clamp, high and low, until I have the shape and locations of the arches correct. I will then start riveting the lengthwise strips to the arches. Once I have the arches rebuilt on the plane, they will have to come back off to get painted.



[2002S2000]

Interesting to follow this, thank you!



[CJD]

While I was machining all those clamps, there was another issue that had been bothering me. The original throttle and fuel mixture knobs are small, plastic balls. Thus giving us the term "balls to the wall", when a fighter pilot wanted all the power he could get out of the engine. Both balls go forward to the firewall.

I tried some new balls off Ebay, but they did not fit and looked cheap...and ugly. Nobody wants cheap, ugly, plastic balls...right? This had to be remedied. They must be bigger, and more substantial...like, say...brass!! That's the ticket, big brass balls!! Lets get to work...

First the balls got digitized into the CNC mill.

Then we popped some brass into the mill.



[CJD]

And now we have some decent sized balls!

The Throttle balls are common brass, while the mixtures are phosphorous bronze, giving them a copper look. They are also a slightly different size, with the letter raised on one and not the other...all to give a different tactile feel, so they will not be confused.

I know. This violates my originality theme. But these are simple, bolt on mods that can be reversed by removing one screw on each ball. I felt it was worth it. The mixture balls will have red paint around the lettering, and the Throttle surrounded and black, to carry the coloring of the original balls. I'll post pics once they are finished and installed.
